# Writing Detectors | Sentry Docs

Detectors identify application issues by

1. Subscribing to data sources
2. Ingesting data packets from data sources and normalizing them
3. Running evaluations against normalized data packets
4. Producing detector occurrences that later get mapped to [Issue Occurrences](https://develop.sentry.dev/backend/issue-platform/producing-occurrences.md)

## [Helpful Context](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#helpful-context)

Detectors are a part of the workflow engine, the section of Sentry that handles all alerts and monitors. Existing workflow engine products include:

* Metric monitors
* Uptime monitors
* Cron monitors
* Alerts

The workflow engine is designed so other product groups at Sentry can build their own detectors on top of it. However, it is still helpful to understand a few key concepts of how it works internally.

### [Detector Data Model](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#detector-data-model)

Each detector is a row in the [`Detector`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/models/detector.py#L95) table. The important fields are:

* `project`: [Project](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/models/project.py#L237) | None
  * The project the detector runs for.
* `type`: str
  * The slug of the [issue type](https://develop.sentry.dev/backend/issue-platform/issue-types.md) the detector creates issues for.
* `config`: dict\[str, Any]
  * Settings specific to your detector type, validated against a JSON schema you provide.
* `workflow_condition_group`: [DataConditionGroup](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/models/data_condition_group.py#L22) | None
  * The trigger conditions (Data Conditions) the detector evaluates.

Detectors get their data through a [`DataSource`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/models/data_source.py#L28), a generic pointer to the product object that produces data, such as a query subscription or an uptime subscription. [`DataSourceDetector`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/models/data_source_detector.py#L8) rows connect data sources to detectors. One data source can feed many detectors.

### [Data Conditions and Data Condition Groups](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#data-conditions-and-data-condition-groups)

A [`DataCondition`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/models/data_condition.py#L121) compares a value against a stored `comparison`. If it matches, it returns its `condition_result`. A [`DataConditionGroup`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/models/data_condition_group.py#L22) combines conditions using a logic type: `ANY`, `ANY_SHORT_CIRCUIT`, `ALL`, or `NONE`.

For detectors, every `condition_result` is a [`DetectorPriorityLevel`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/types.py#L62): `OK`, `LOW`, `MEDIUM`, or `HIGH`. The detector uses the highest priority among the conditions that match.

For example, a detector watching a count could use an `ANY` group with these conditions:

| `type` | `comparison` | `condition_result` |
| ------ | ------------ | ------------------ |
| `gt`   | `10`         | `HIGH`             |
| `gt`   | `5`          | `MEDIUM`           |
| `lte`  | `5`          | `OK`               |

A value of `7` matches one condition and returns `MEDIUM`. A value of `12` matches the `MEDIUM` and `HIGH` conditions, but since `HIGH` is a higher priority, it returns `HIGH`.

### [When Detectors Are Evaluated](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#when-detectors-are-evaluated)

Detectors don't poll for data. Instead, your product code wraps its data in a [`DataPacket`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/models/data_source.py#L22) and passes it to the workflow engine:

```python
process_data_packet(
    DataPacket(source_id=str(source.id), packet=payload),
    DATA_SOURCE_EXAMPLE,
)
```

The [`process_data_packet`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/processors/data_packet.py#L8) function looks up the enabled detectors connected to the packet's data source and evaluates each one. Any occurrences or status changes they return are sent to the issue platform. To learn more about this process, refer to [Producing Occurrences](https://develop.sentry.dev/backend/issue-platform/producing-occurrences.md).

If your product already knows which detectors to run, call [`process_detectors`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/processors/detector.py#L339) with the packet and those detectors instead.

### [Additional Documentation](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#additional-documentation)

Interested in learning more about how the workflow engine works? [Refer to the documentation in the Sentry codebase](https://github.com/getsentry/sentry/tree/7d380ec/src/sentry/workflow_engine/docs).

## [Writing a Detector](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#writing-a-detector)

### [Pick A Base Class](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#pick-a-base-class)

Detector handlers are generic over two types:

* `DataPacketType`: The payload your product puts in the `DataPacket`.
* `DataPacketEvaluationType`: The value your handler extracts from the payload and evaluates against the detector's conditions.

For example, [`UptimeDetectorHandler`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/uptime/grouptype.py#L105) is a `StatefulDetectorHandler[UptimePacketValue, CheckStatus]`. It receives uptime check results and evaluates whether each check succeeded or failed.

There are three base classes to choose from:

* [`BaseDetectorHandler`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/handlers/detector/base.py#L102): The abstract interface. Don't inherit from this unless you have a specific reason. The only direct subclass is [`ErrorDetectorHandler`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/grouping/grouptype.py#L29), a placeholder that links error issues to a detector and is never evaluated.
* [`DetectorHandler`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/handlers/detector/base.py#L156): The default for new detectors. It evaluates each packet on its own and creates an occurrence whenever the conditions return a priority above `OK`.
* [`StatefulDetectorHandler`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/handlers/detector/stateful.py#L312): Use this if you need state between packets, such as deduplication, thresholds (for example, "fail 3 times before creating an issue"), or resolving issues when the data recovers. Uptime and metric detectors use this.

## [Implement Abstract Methods](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#implement-abstract-methods)

`DetectorHandler` has two abstract methods:

* `extract_value`: Returns the value to evaluate from the packet. To track independent substreams, like one per endpoint, return a dict of group key to value instead. Each group key gets its own issue, so keep the number of keys bounded.
* `create_occurrence`: Returns a [`DetectorOccurrence`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/handlers/detector/base.py#L54) and event data describing the issue. It's called when the conditions return a priority above `OK`. Under this hood, this will be converted to an [Issue Occurrence](https://develop.sentry.dev/backend/issue-platform/producing-occurrences.md).

`StatefulDetectorHandler` adds a third:

* `extract_dedupe_value`: Returns a positive integer that increases with packet order, like a sequence number or timestamp. Packets with a value no higher than the last one seen are skipped.

Here's an example stateful handler:

```python
@dataclass(frozen=True)
class ExamplePacket:
    value: float
    sequence: int

class ExampleDetectorHandler(StatefulDetectorHandler[ExamplePacket, float]):
    def extract_value(self, data_packet: DataPacket[ExamplePacket]) -> float:
        return data_packet.packet.value

    def extract_dedupe_value(self, data_packet: DataPacket[ExamplePacket]) -> int:
        return data_packet.packet.sequence

    def create_occurrence(
        self,
        evaluation: DataConditionGroupEvaluation,
        data_packet: DataPacket[ExamplePacket],
        priority: DetectorPriorityLevel,
    ) -> tuple[DetectorOccurrence, EventData]:
        occurrence = DetectorOccurrence(
            issue_title=f"{self.detector.name} triggered",
            subtitle="The monitored value crossed its threshold",
            evidence_data={"value": data_packet.packet.value},
            evidence_display=[],
            type=ExampleGroupType,
            level="error",
            culprit="",
            priority=priority,
        )

        return occurrence, {}
```

## [Register Your Detector](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#register-your-detector)

Every detector type is tied to an issue type. First, [register a `GroupType`](https://develop.sentry.dev/backend/issue-platform/issue-types.md#register-an-issue-type) for the issues your detector creates, if one does not exist already. Then register a [`DetectorSettings`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/types.py#L288) subclass under the group type's slug:

```python
@detector_settings_registry.register(ExampleGroupType.slug)
class ExampleDetectorSettings(DetectorSettings):
    handler = ExampleDetectorHandler
    validator = ExampleDetectorValidator
    config_schema = {
        "$schema": "https://json-schema.org/draft/2020-12/schema",
        "type": "object",
        "properties": {"threshold": {"type": "integer", "minimum": 1}},
        "required": ["threshold"],
        "additionalProperties": False,
    }
```

* `handler`: Your handler class.
* `validator`: A subclass of [`BaseDetectorTypeValidator`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/endpoints/validators/base/detector.py#L66). The detector API uses it to create and update detectors of your type.
* `config_schema`: The JSON schema for `Detector.config`.
* `filter` (optional): A `Q` filter that controls which detectors of this type are visible to users.

Registration happens at import time. Put both classes in your product's root `grouptype.py`, or import them from it, so Sentry registers them on startup.

If your product uses a new kind of data source, also implement a [`DataSourceTypeHandler`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/types.py#L176) and register it with `data_source_type_registry`.

## [Provision Your Detector Rows](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#provision-your-detector-rows)

When making a detector, you have to provision rows in a few tables:

* `Detector`
* `DataCondition`
* `DataConditionGroup`
* `DataSource`
* `DataSourceDetector`

Decide from the two following ways to provision these rows:

* **From the UI**: Add a creation form for your detector type in the frontend. See the existing forms in [`static/app/views/detectors/components/forms/`](https://github.com/getsentry/sentry/tree/7d380ec/static/app/views/detectors/components/forms). The UI calls the detector API, and your validator creates the detector, its conditions, its data source, and the `DataSourceDetector` row in one transaction.
* **With a data migration**: Use this when detectors should exist without any user input. See [Database Migrations](https://develop.sentry.dev/backend/application-domains/database-migrations.md), and [`0117_backfill_all_project_detectors`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/migrations/0117_backfill_all_project_detectors.py) for an example. The migration has to create the related rows itself, and it only covers projects that exist when it runs.

## [Customization](https://develop.sentry.dev/backend/issue-platform/writing-detectors.md#customization)

The default `evaluate` methods implemented in the detector base classes cover most use cases. For small changes, override a hook instead:

* [`get_issue_fingerprint`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/handlers/detector/base.py#L318) (`DetectorHandler`): Replaces the default `detector:<detector_id>` fingerprint.
* [`build_issue_fingerprint`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/handlers/detector/stateful.py#L352) (`StatefulDetectorHandler`): Adds components to the fingerprint.
* [`thresholds`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/workflow_engine/handlers/detector/stateful.py#L336) (`StatefulDetectorHandler`): Sets how many matching evaluations are needed before the detector changes priority. The default is one.

Be careful with fingerprint changes. They can split or merge existing issues.

If your detector needs a different flow, override `evaluate`. You are then responsible for orchestrating extracting values from the data packet, evaluating data conditions, and build results. For examples, see:

* [`PreprodSizeAnalysisDetectorHandler`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/preprod/size_analysis/grouptype.py#L194): Overrides `DetectorHandler.evaluate`.
* [`ProcessingErrorDetectorHandler`](https://github.com/getsentry/sentry/blob/7d380ec/src/sentry/processing_errors/grouptype.py#L75): Overrides `StatefulDetectorHandler.evaluate` to skip dedupe and thresholds.
